Type

Vertical (full automatic)

Heating method

Electric

Power supply

AC220V/50HZ

Sterilizing temperature

50℃

Working pressure

-50pa

Sterilize agent

Hydrogen peroxide solution(60%H202)

Sterilizing time

45-50min

Display

LCD screen

Chamber material

304 anti-corrosion type stainless steel or aluminum 5052

Carton material

ABS

Electrode material

Aluminum alloy material 5052, sheet metal forming, thickness ≥ 3 mm

Sealing door material

Use 5052 aluminum alloy material, thickness ≥ 15 mm

Door open mode

using mandrel drive electric lift door

Door protection function

With door barrier switch function, when touch the barrier switch, the door automatically stop, to prevent injure the operator and damage the items

Full automatic control system

LCD touch screen display, PLC intelligent control system. One button to control from start to end and finish automatically with showing temperature, pressure, sterilization time

Printer

Adapting to micro printer to printing each data of every minute during the sterilization process, also can storage permanently

PLC

Use imported Siemens smart series PLC control system

U disk storage function

Disk capacity ≥ 8G, it can store records more than one million sterilization data, storage information

Biological Indicator Cultivator

Microcomputer-controlled biological indicator special temperature incubator for the monitoring of biological effects of biological indicators of the constant temperature culture process

Program System

There are two procedures to strengthen the cycle and fast cycle. Strengthen the cycle ≤ 50 minutes, fast cycle ≤ 30 minutes

Sterilization effect

Domestic first invent that can make cavity instrument disinfect thoroughly from 2 meters to 4 meters. Offer provincial sterilization effect certificate report.

Heating system

Adapting to anti-explosion and fire resistance heating system, temperature is more precise, more convenient and fast

Various protective function

It has set up over temperature protection function and show on LCD screen if fault, to make the after sales-service dealing with fault more efficiently.
